Double Seam System 200B

Double Seam System 200B is the smallest computer system for beverage can quality control. The system performs the external measurement of can height, countersink depth, seam height and seam thickness. Metop high-quality measuring system features the inner surface quality control of end hook, body hook, overlap, seam gap and calculated body hook butting. Double Seam System 200B is equipped with user-friendly Winseam 5.0 software and integrated database. All external measurements are transmittted into the measuring report. All internal measurements are made automatically using camera and vision measuring system. The system monitors all seam dimensions and indicates critical errors.

Double Seam System 200B includes:

• Winseam Software
• Metop Seam Saw (MSS-2B)
• Vision Seam Computer of 3rd Edition (VSC-3)
• Manual Seam Cutter (MSC-3B)
• Metop Industrial Computer (MCO-2)
• Seam Thickness Gauge (STH-3B)
• Metop Combi Gauge (MCG-3B)
• Optional: Semi-Automatic Rotating Cutter (SARC-3)

Main features:

• UPS with uninterruptible power source (230 V)
• Laser printer (230 V)
• Industrial solid 15” screen
• Toolbox
• Keyboard, mouse and all required cables
• Foot pedal
• 3-year warranty
• High Swedish quality
