Single-channel ozone controller for continuous measurement with electrochemical O₃ sensors. Designed for wall-mount installation, featuring universal power supply, analog outputs, and external pressure compensation.
On order
510CC0/W1C0P000 Orbisphere 510 Controller O₃ (EC), Wall Mount, 100–240 VAC, 0/4–20 mA, External Pressure
510CC0/W1C0P000
Orbisphere
Description
The Orbisphere 510 Controller O₃ (EC) is a single-channel controller designed for continuous ozone measurement using Orbisphere electrochemical (EC) ozone sensors. The controller provides stable signal processing, real-time measurement display, and configurable outputs for integration into process control systems. Its wall-mount enclosure, universal AC power supply, and support for external pressure compensation make it suitable for accurate ozone monitoring in demanding industrial and laboratory environments.
Advantages of 510CC0/W1C0P000
- Dedicated mono-channel controller for electrochemical ozone sensors — 510CC0/W1C0P000.
- Wall-mount design for permanent installation in control rooms and laboratories.
- Universal 100–240 VAC power supply for worldwide operation.
- Configurable 0/4–20 mA analog output for process integration.
- External pressure input for compensated ozone measurement.
Operating instructions
Mount the controller vertically on a wall using the designated mounting points. Connect the compatible Orbisphere electrochemical ozone sensor to the controller input. Supply power using a 100–240 VAC source and connect the analog output to the control or monitoring system. If required, connect an external pressure signal for measurement compensation. Perform sensor configuration and calibration according to the manufacturer’s manuals and verify operation periodically.
Technical Specifications
| Parameter | Specification |
|---|---|
| Article number | 510CC0/W1C0P000 |
| Product type | Ozone controller |
| Measured parameter | Ozone (O₃) |
| Sensor technology | Electrochemical (EC) |
| Number of channels | 1 |
| Mounting type | Wall mount |
| Power supply | 100–240 VAC |
| Analog output | 0/4–20 mA |
| External pressure input | Supported |
| Application | Industrial and laboratory ozone monitoring |
| Manufacturer | Hach |
| Brand | Orbisphere |
