The EBI 300 TE is a versatile, high-performance USB data logger designed for the simultaneous monitoring of ambient and core temperatures. Equipped with an external stainless steel penetration probe, it is specifically engineered for the pharmaceutical, logistics, and food industries to ensure the safety of temperature-sensitive goods during transport and storage.
The EBI 300 TE (Part No. 1340-6335) stands out for its "plug-and-play" evaluation system. It features an integrated USB interface that allows it to be connected to any PC without the need for additional docking stations or proprietary software. Upon connection, the logger automatically generates a comprehensive PDF report containing the temperature curve and all limit violations. The device utilizes an internal NTC sensor for ambient air and an external NTC probe (TPC 300) with a 1-meter food-safe cable for precise core measurements. It is fully compliant with HACCP, EN 12830, and FDA 21 CFR Part 11, providing a tamper-proof and cost-effective solution for digital cold chain documentation.
Advantages
- Automatic PDF Generation: Provides immediate access to measurement data on any computer without installing special software.
- Dual Sensor Technology: Measures both the surrounding environment and the internal product temperature simultaneously via the external probe.
- Replaceable External Probe: The digital interface allows the external sensor to be swapped easily for calibration or replacement without sending in the main unit.
- High Memory Capacity: Capable of storing up to 40,000 measurement values for long-duration transport monitoring.
- Rugged & Food Safe: Features an IP65 protection rating and a 1-meter PVC cable that is waterproof, oil-proof, and suitable for direct food contact.
- Cost-Efficient: Eliminates the need for expensive interfaces and reduces IT and training costs through its intuitive, button-based operation.
Instructions for use
The EBI 300 TE is designed for straightforward deployment in the field or warehouse. Preparation: Program the logger using ebro’s free online configurator (www.ebi300.com) or the Winlog software. Set your desired measurement interval (1 min to 24 h) and alarm thresholds. Note: Press the "Start" button to begin recording. Place the logger in the transport container and insert the external probe into the product or a dummy sample. After the journey, plug the logger into a USB port to retrieve the automatically generated PDF report. The device can be reset and reused immediately for the next shipment.
Technical specifications
| Catalogue number | 1340-6335 |
| Brand | ebro® (Xylem) |
| Measuring Range (Internal) | -30 °C to +70 °C (-22 °F to +158 °F) |
| Measuring Range (External) | -35 °C to +70 °C (-31 °F to +158 °F) |
| Accuracy | ±0.5 °C (-20 °C to +40 °C); ±0.8 °C for remaining range |
| Resolution | 0.1 °C |
| Memory | 40,000 measurements |
| External Probe | NTC, Stainless steel, Ø 4 mm, L = 50 mm, 1 m PVC cable |
| Protection Class | IP65 |
Available packaging options
| 1340-6335 | EBI 300 TE PDF Data Logger with External Probe |
| Brand | Ebro |
