The ebro TFX 430 is a high-precision reference thermometer designed for laboratory use, quality assurance, and industrial process monitoring. Utilizing advanced Pt 100 technology, it offers laboratory-grade accuracy in a rugged, portable housing, making it one of the most precise handheld thermometers in the ebro range.
The TFX 430 (Part No. 1340-5430) is a top-tier measurement instrument engineered for applications where every hundredth of a degree matters. It features a wide measurement range from -100 °C to +400 °C and utilizes a Pt 100 sensor for maximum stability and resolution. The device boasts an impressive resolution of 0.01 °C within the most critical range and a system accuracy of up to ±0.05 °C. This model is supplied without a probe, featuring a universal connection that allows it to be paired with various high-precision Pt 100 sensors. The housing is made of impact-resistant ABS plastic and is certified to IP67 protection class, ensuring it is completely dust-tight and waterproof. It is powered by a high-capacity CR 2477 lithium battery and includes a factory calibration certificate to ensure traceable accuracy for auditors and quality managers.
Advantages
- Exceptional Precision: Delivers an accuracy of ±0.05 °C, making it ideal as a secondary reference standard for calibrating other thermometers.
- High Resolution: The 0.01 °C resolution allows for the detection of the smallest temperature fluctuations in sensitive chemical or biological processes.
- Robust and Waterproof: The IP67 rating ensures the device can be fully immersed for cleaning and remains functional in harsh industrial environments.
- Adjustable Measurement Interval: The sampling rate can be set between 1 and 15 seconds, allowing the user to balance data detail with battery life.
- Flexible Configuration: The exchangeable probe system allows for the use of various specialized Pt 100 sensors for different media and temperatures.
- Long Battery Life: Equipped with a 3 V / 1 Ah CR 2477 lithium battery, ensuring long-term availability for continuous monitoring tasks.
Technical specifications
| Catalogue number | 1340-5430 (TFX 430) |
| Sensor type | Pt 100 |
| Measurement range | -100 °C ... +400 °C |
| Accuracy | ±0.05 °C (-50.00 °C ... +199.99 °C); ±0.2 °C for remaining range |
| Resolution | 0.01 °C (-100 °C ... +199.99 °C); 0.1 °C for remaining range |
| Measurement interval | 1s ... 15s |
| Protection class | IP67 |
| Dimensions | 109 x 54 x 22 mm (without probe) |
| Weight | approx. 90 g |
| Battery | 3 V / 1 Ah Lithium (Type CR 2477) |
| Brand | Ebro |
